RAM 824 ALL TERRAIN is the Pipe and Fittings Fusion Machine designed to face the toughest working conditions.

RAM 824 ALL TERRAIN wants to mark a turning point to the world of Field Fusion. It stands out for being extremely easy to set up and work with. Take the heating plate and facer disconnecting system for example; the positioning / removal of the pipes is made without obstacles, giving the operator more time for what really matters.

Italian design, known for paying particular attention to details, gives  RAM 824 ALL TERRAIN many technical innovations that are indeed practical. Take the clamps hydraulic system, for instance - not only an aesthetical maneuver, but a protection against collisions while positioning the machine inside the trench. Take the low fuel consumption and soundproofing gear– protects the environment, your health and saves you money!

- Working range: Ø 8" IPS - 24" DIPS (225 - 655 mm)
- 4 steering wheels drive
- Diesel-engine
- Self-contained with on-board generator
- Sliding 3rd CLAMP for fittings welding
- Automatic welding System “Easy Life”
- DATA-LOGGING with gps
- Detachable Control Panel
- Trench-Friendly
- SmartLock Inserts
- Hydraulic Lifts
- Hydraulic-controlled Clamps and Milling cutter
- Climbs rough terrain up to 30%
